Product details

Main structure	Galvanized steel structure
Product Type	Foldable container house
Application	Office/Shop/Dormitory
Place of Origin	Shandong, China
Brand Name	Sunrises House
Product name	Z440
Advantage	Quick Installation
Keyword	Foldable Container House
Material	Steel + Sandwich Panel
Transport and load	Container Shipment
Wall	50mm sandwich panel
Floor	Cement fiberboard
Window	Plastic steel framed window
Certification	CE/FSC/ISO9001

product-790-982

product-800-800

product-1-1

Product Features

product-1-1

Product Case

Package and delivery

product-800-800

FAQ

Q: What is your delivery time?

A: Generally we arrange shipment within 7-10 days after receiving the deposit. For large orders, the delivery time will be confirmed through negotiation with the customer.

Q: Can you send engineers or whole team to install my project?

A: We will give detailed installation drawings and video for free.We can send engineers as installation director or a team upon request if you really need them to,but you should pay the costs for that.

Q: How can we get a quotation for our projects?

A: You can contact us by email,phone,TM,Whatsapp,Skype and so on 24*7 and you will get quick reply.

Q: Do you accept container loading inspection?

A: You are welcomed to send an inspector,not only for container loading,but any time during the production time.

Hot Tags: Foldable Container House WIth Solar Panels, China Foldable Container House WIth Solar Panels manufacturers, suppliers, factory, contena house, prefab container house, cottage container homes, cantilever container house, container house, ready container house

Specifications of the Quick Assembly Container House

Item	Specification
Steel Frame Structure Bare Steel 2.0mm	2.0mm galvanized steel strip--top beam, section width 180mm 210150210 high-end galvanized angle pieces - 4 pieces 4 pieces of transverse galvanized 4060mm square tube secondary top beams, 1 piece of longitudinal 4080mm galvanized square tube, 2 pieces of 40*60mm galvanized square tubes 75mm glass wool insulation quilt, 14kg/m³ 0.4mm color steel single tile
	2.0mm galvanized steel strip--bottom beam, 160mm section width roller beam, 4 pieces of 210150160 high-end galvanized angle pieces, 9 pieces of galvanized 401001.1mm square tube galvanized cross braces, 1 piece of longitudinal 40401.1mm (square tube)
	2.0mm galvanized steel strip--column, 210/150mm in width, 2526mm in height 8.0mm L-shaped column stiffeners (connecting parts) Equipped with connecting plates for upper, lower, left and right connections between boxes, and 12*30 hexagon socket bolts
Ceiling Tile	0.3mm/831 ceiling tile
Bottom	Flashing parts, 50mm/75mm optional
Flooring	5 pieces of 18mm thick cement fiberboard
Flooring finishes	1.0mm Grade B plastic floor
Door	9701970 mid-range steel door (9701970, flat panel insert frame, AB lock, for 50 wall panel)
Windows	Plastic-steel windows (single-glazed with anti-theft grilles, 930*1130mm, 2 pieces (exclusively for 50 wall panels))
Wall Panel	50/950mm, double-sided 0.3mm orange peel texture, 70KG bulk density, film-coated and including pallets
Downspouts	50mm, PVC downspouts, 4 pieces
Ceiling Trim	Homogeneous parts for 4*4 831 ceiling tiles used in ceiling
Internal corner of a column	Galvanized steel internal corner line, white lime
Accessories	5 tubes of structural adhesive, 80 pieces of 420 round-head self-drilling screws, 60 pieces of 1275/12100 hexagon self-drilling screws, 40 pieces of 425 self-tapping screws, 1 set of connecting bolts
Electric System	Electrical distribution (three-core), 6㎡ incoming line, 4m², 2.5m², 1.5㎡ copper wires Three sockets One single-pole switch Two lamps One set of distribution box One industrial plug and one industrial socket
Packaging	Main profiles wrapped with bubble wrap, loose parts loaded into the container
